2. Large air volume, strong cooling, low energy consumption, low noise, long life and stable operation.
3. Use advanced R410A refrigerant, green, healthy and comfortable.
4. Using advanced imported compressors, it can effectively cool in the high temperature environment of 45 °C.
4. Using advanced imported compressors, it can effectively cool in the high temperature environment of 45 °C.
5. Use automatic control system with automatic diagnosis function to effectively prevent damage to the machine caused by bad operation.
6.BXT-cool series is the most convenient air conditioner on the market;
7. As long as the plug is plugged into the power outlet, the source of cold air is continuously spewed out; large air volume, good cooling effect.
Applicable places:
1. Hospitals, research institutes, disaster scene rescue.
2. Automobile repair center, manufacturing engineering for cooling.
3. Temporary office space, such as the reception room, equipment is cooled centrally.
4. Factory production workshop, canteen, warehouse, on-site office.
5. Outdoor activities such as golf driving range, various celebrations, temporary construction of greenhouses.
Technical Specifications:
| Model | BXT-28 | BXT-45 | BXT-45D | BXT-50 | BXT-55 | BXT-65 | BXT-65B | BXT-85 | BXT-150 | BXT-180 | BXT-250 | BXT-280 | |
| Power supply | Single phase 220V/50Hz |
Single phase 220V/50Hz |
Single phase 220V/50Hz |
Single phase 220V/50Hz |
Single phase 220V/50Hz |
Single phase 220V/50Hz |
Single phase 220V/50Hz |
Three phase 380V/50Hz |
Three phase 380V/50Hz |
Three phase 380V/50Hz |
Three phase 380V/50Hz |
Three phase 380V/50Hz |
|
| Refrigerating Output |
KW | 2.8 | 4.5 | 4.5 | 5 | 5.5 | 6.5 | 6.5 | 8.5 | 15 | 18 | 25 | 28 |
| BTU | 9650 | 15500 | 15500 | 16500 | 18700 | 22000 | 22000 | 28900 | 51100 | 61200 | 85300 | 95200 | |
| Cold air output(m³/h) | 500 | 650 | 650 | 850 | 780 | 910 | 1100 | 1550 | 2600 | 2800 | 3500 | 5000 | |
| Consumed power(KW) | 1 | 1.4 | 1.4 | 2.1 | 1.8 | 2.4 | 2.5 | 3.25 | 5.5 | 6 | 11.3 | 5.5*2 | |
| Current operation(A) | 5 | 7.4 | 7.4 | 10 | 10.4 | 10.8 | 11.5 | 7 | 10.5 | 11.6 | 20 | 24 | |
| Tank capacity(L) | 5 | 14 | 14 | 8 | 14 | 14 | 13 | External | External | External | External | External | |
| Product size(mm) | W 430 D 400 H 840 |
W 450 D 510 H 1100 |
W 450 D 510 H 1100 |
W 485 D 520 H 1180 |
W 520 D 625 H 1100 |
W 560 D 630 H 1260 |
W 520 D 575 H 1290 |
W 810 D 1050 H 1000 |
W 1360 D 810 H 1000 |
W 1480 D 850 H 1070 |
W 1405 D 900 H 1530 |
W 1405 D 900 H 1530 |
|
| Packing size(mm) | W 484 D 515 H 965 |
W 520 D 575 H 1210 |
W 520 D 575 H 1210 |
W 550 D 580 H 1300 |
W 610 D 700 H 1210 |
W 645 D 715 H 1575 |
W 630 D 700 H 1600 |
W 880 D 1120 H 1150 |
W 1430 D 885 H 1150 |
W 1580 D 950 H 1180 |
W 1480 D 980 H 1580 |
W 1480 D 980 H 1580 |
|
| Gross weight(kg) | 50 | 65 | 65 | 80 | 84 | 128 | 100 | 160 | 220 | 245 | 420 | 420 | |
| Net weight(kg) | 45 | 60 | 60 | 75 | 78 | 100 | 90 | 120 | 185 | 200 | 350 | 350 | |
| Operating environment | 18-45℃ | ||||||||||||
